Product Model: TC15
Brand: Zebra
Category: Barcode Scanner
Meet the challenges of the on-demand economy, with easy access to information on the go. Introducing TC15 - a rugged mobile computer designed to be used in different environments, from transportation and logistics to retail, with proven technology and a new level of affordability—built for your supply chain.
Key Features
| Characteristic | Specification |
|---|---|
| Display | 6.5-inch HD+ (720 x 1600), 450 NITS, capacitive multi-touch screen |
| Operating System | Android 11, with built-in support for future Android releases and upgradeable to Android 14 |
| Processor (CPU) | Qualcomm Snapdragon SM6375 Octa-Core (2.2 GHz & 1.8 GHz) |
| Memory | 4 GB RAM / 64 GB Flash storage |
| Scanner | Integrated SE4710 1D/2D imager for barcode capture |
| Connectivity | 5G WWAN, Wi-Fi (WLAN, Wi-Fi 6 ready), Bluetooth 5.1, NFC, USB-C |
| Durability | Rugged design, IP67 sealed (waterproof/dustproof), 1.2m (4 ft) drop to concrete (1.5m with bumper) |
| Battery | Removable, rechargeable 5,000 mAh Li-Ion battery with fast charging support |
| Camera | 13 MP auto-focus rear camera and 5 MP front camera |
| SIM Support | Dual nano SIM or one nano SIM and one Micro SD card slot |
Physical Characteristics
|
Dimensions |
6.92 in. L x 3.09 in. H x 0.56 in. D |
| Weight | 9.38 oz/266 g |
| Display | 6.5 inch/16.51 cm HD+, 720 x 1600, 450 NITS |
| Touch Panel | Capacitive multi-touch |
| Power | Removable, rechargeable Li-Ion battery, 5,000 mAh; 19.35Wh |
| SIM | Dual nano SIM or One NANO one Micro SD |
| Network Connections |
WLAN, WWAN, WPAN, Type C USB 2.0 |
| Notifications | Audible tone; multi-color LEDs; vibration |
| Keypad | On-screen touch keypad |
| Voice and Audio |
Speaker 1 Watt |
| Buttons | Scan button on each side; volume up/down button; power button; Programmable button |
Performance Characteristics
| CPU |
Qualcomm Snapdragon™ SM6375 |
| Operating System | Android; for supported Android versions, visit: www.zebra.com/android-versions |
| Memory | 4 GB RAM/64 GB Flash |
| Security | Verified boot, secure boot |
User Environment
| Operating Temp. | 14°F to 122°F/-10°C to 50°C |
| Storage Temp. | -40°F to 158°F/-40°C to 70°C |
| Humidity | 5% to 95% non-condensing |
| Drop Specifications |
4 ft./1.2 m drop to concrete per MIL-STD 810G across operating temperature |
| Tumble Specification |
1,000 tumbles, 1.6 ft./0.5 m |
| Sealing | IP65 and IP67 |
| Vibration |
Sine: 4 g’s peak, 5 Hz to 2 kHz, 1 hour duration per axis |
|
Electrostatic |
+/-15 kV air discharge, +/- 8 kV direct discharge; +/- 8 kV indirect discharge |
Interactive Sensor Technology (IST)
| Light Sensor | Automatically adjusts display brightness, display backlight |
| Motion Sensor | 3-axis gyroscope; 3-axis accelerometer |
| Proximity Sensor | Automatically detects when the user places the handset against head during a phone call to disable display output and touch input |
Data Capture
| Scanning | SE4100 1D/2D Scan Engine, SE4710 1D/2D Scan Engine3 |
| Camera |
Rear camera: 13 MP auto-focus camera with user controllable LED flash |
| NFC | Reader/Writer: ISO 14443 Type A and B, MIFARE, FeliCa™, ISO 15693, NFC Forum Tag Types 1 to 5; Host Card Emulation, NFC Forum compliant |
Wireless WAN Data
| Radio Frequency Band |
Support for 3GPP Rel-15,SA&NSA,4x4 |
| GPS | GPS with A-GPS; Glonass; BeiDou; Galileo |
Markets and Applications
Transportation and Logistics
Retail and Hospitality
Field Service
Manufacturing/Warehousing
